supply hot medium frequency induction heating equipment suit-凯发备用官网

 items

unit

kgps-30

kgps-60

kgps-100

kgps-200

dia of workpiece

mm

φ100-300

φ300-500

φ500-1000

φ1000-3000

height of workpiece

mm

100-500

200-600

500-1200

1000-2000

power

kw

30

60

100

200

heating temperature

℃

800

800

500

500

usage

suitable for df,dn,ss,6k,8k series motor and other types locomotive gear hoops induction heating dismounting

feature

high performance ,high heating speed and wide usage.it can be automatically controlled by a setting time and a setting temperature,it do not need to preheat before turn on, when turn off,there was no waste heat ,also with feature of simply operating and maintenance .

construction and function

the equipment is a kind of ac-dc-ac static variable frequency  energy saving device,which is mainly composed of medium frequency power supply cabinet,temperature control and test device,timing device,induction coil ,wheel hoop positioning and lifting mechanism.the power can be adjustable within range of 0% ~ 90%,suitable for various kind of locomotive hoop heating,with characteristics of fast heating ,uniform temperature ,convenient use etc.....it is the ideal equipment for the overhaul of the wheel.

the power supply cabinet dimension

1800mm×860mm×680mm

induction coil

custom made

input supply power

ac380v,50hz
