resistnace heating lab furnace

type：laboratory furnace

input size：custom made

leave message

overview
specifications
features

application :

the equipment mainly used in the ht heating treatment on carbon material, carbon nano, carbon fiber, negative electrode materials, graphite powder, contacting terminal material and such related material.

the furnace picture:

all our furnace can be custom made:

		nti-thl-54w
working size （l×w×h）	mm	300x300x600
heating type	/	graphite rod
power control	/	thyristor controlled
max. capacity	l	54
loading capacity	g	ht area capacity × product’s density(g/cm³)×1000 1l=1000cm³
input voltage	/	380v±10%，50hz/60hz 3 phase 5 wire
equipment structure	/	one power to one or two or four furnace
type	/	horizontal
power	kw	50
max. temperature	℃	1600
working tem.	℃	1500
tem.uniformity	℃	±5
working environment	/	vacuum or argon、n₂atmosphere environment (micro-positive pressure)
