cooling tower fbp-6a

type：other related products

input size：2500×1200×2600

leave message

overview
specifications
features

model	fbp-6a
series no	name	unit/ value
1	working flow amount	26-45m³/h
2	cooling amount	180000kcal/h
3	in and out pipe diameter	dn65
4	red copper pipe	φ16mm t0.6mm
5	spraying pump parameter	12.5m 25m³/h 1.5kw
6	water pump	38m 43.5m³/h 7.5kw
7	working pressure	0.3mpa
8	draught fan parameter	13000m³/h 1.1kw×2 set
9	draught diameter	φ750
10	rated voltage	380v-50hz
11	net weight(empty chamber situation)	1400kg
12	outer size（mm）	2500×1200×2600
