new type 2300 degree carbonization furnace-凯发备用官网

 the main technical parameters:

 ●feature:

1. the high temperature furnace body is within 2200 degrees celsius, and can be compatible with various carbonization and sintering craft. this equipment adopts the front door or front and back double doors, with excellent resistance structure and density. the continuous vacuum carbonization sintering craft can be realized; the system is provided with a decoking system, the effect of the decoking is enhanced, the atmosphere in the furnace is more stable, the product quality is easy to be controlled, and the service life of the carbon felt and heating material is prolonged.

2.adopting resistive heating, the service life of the graphite tube is long, excellent heating efficiency, convenient maintain. uniform heating, reliable insulation and temperature measuring system, advanced furnace hearth design concept, reasonable heating structure, high quality materials to ensure vacuum furnace temperature uniformity. adopt the domestic and international brand temperature measuring elements to ensure the accuracy of the temperature measurement. the advanced temperature control system, imported digital display intelligent temperature control meter, plc and practical data communication, automatic high precision finish temperature measure and control, the system can rise temperature according to the given curve, and can store 4 sections in total 40 segments different heating process curve. single room, horizontal structure, equipment layout is compact and reasonable, covers an area of small.

3. advanced automation control, plc water, electricity and gas comprehensive automatic control and protection system, plc safety chain, with sound and light alarm function for over temperature, sensor fault, water-pressure, furnace overpressure, water flow, water temperature too high. environmental protection, energy saving, non purification of the essence of the vacuum exhaust gas, effective protection of the normal operation of the vacuum pump and a good effect of decoking.

4. the cooling of the furnace body is cooled by natural cooling, and the low temperature section can be cooled by charging a positive pressure inert gas to increase the cooling speed. exclusive design of the furnace body explosion-proof valve, safe and reliable.

the furnace suitable for :

the standard export packing:
